Cisco ASA 5525-K9 là tường lửa thế hệ tiếp theo của Dòng ASA 5500-X. Cisco ASA 5500-X Series cung cấp khả năng bảo mật mạng sâu rộng thông qua một loạt các dịch vụ tường lửa dựa trên nền tảng đám mây và phần mềm tích hợp cung cấp tính linh hoạt của dịch vụ, khả năng mở rộng mô-đun và khả năng mở rộng tính năng nhằm giảm chi phí triển khai và vận hành. ASA 5525-K9 hỗ trợ chuyển đổi dự phòng Active / Active và Acitve / standby để cho phép dự phòng tường lửa.
Giới thiệu chung về Firewall Cisco ASA5525-K9:
ASA 5525-K9
750 IPSec VPN peers, up to 2 Gbps stateful inspection throughput, 500,000 Concurrent Connections
Cloud- and Software-based Firewall services, 3DES/AES, 2 SSL VPN peers
8 copper GE ports, 1 copper GE management port, 1 expansion slot
Cisco Application Visibility and Control (AVC), Cisco Web Security Essentials (WSE)
Active/Active, Active/Standby high availability, 200 Vlans
8 GB memory, 8 GB flash
- Cisco ASA 5525-K9 is the next-generation firewall of ASA 5500-X Series. Cisco ASA 5500-X Series provides deep network security through an array of integrated cloud-base and software-based firewall services offering service flexibility, modular scalability and feature extensibility in order to reduce deployment and operation costs. ASA 5525-K9 supports Active/Active and Acitve/standby failover to enable the firewall redundancy.
- ASA 5525-K9 delivers superior performance with up to 2 Gbps stateful inspection throughput, 750 IPsec VPN peers, 500,000 concurrent connections and 1 expansion slot makes it ideally suited for the small, mid-size enterprises, branch offices or internet edge deployments while delivering enterprise-strength security. The Multiple security services and redundant power supplies enable consistent security implementation; the cloud-base and software-base modular enable security services, such as IPS, Cisco Application Visibility and control (AVC), Cisco Web Security Essentials (WSE), and Cisco Cloud Web Security (CWS).
Thông số kĩ thuật:
- Thông số chi tiết Firewall Cisco ASA5525-K9:
Feature | ASA5525-K9 |
Stateful Inspection Throughput (Maximum) | 2 Gbps |
Stateful Inspection Throughput (Multiprotocol) | 1 Gbps |
IPS Throughput | 600 Mpbs |
Next-Generation Throughput(Multiprotocol) | 650 Mbps |
3DES/AES VPN Throughput | 300 Mbps |
Users/Nodes | Unlimited |
IPsec VPN Peers | 750 |
Cisco Cloud Web Security Users | 4,000 |
Premium AnyConnect VPN Peers(Included/Maximum) | 2/750 |
Concurrent Connections | 500,000 |
New Connections/Second | 20,000 |
Virtual Interfaces (VLANs) | 200 |
Security Contexts (Included/Maximum)6 | 2; 20 |
High Availability | Active/Active and Active/Standby |
Expansion Slot | 1 interface card |
User-Accessible Flash Slot | 0 |
USB 2.0 Ports | 2 |
Integrated I/O | 8 GE Copper |
Expansion I/O | 6 GE Copper or 6 GE SFP |
Serial Ports | 1 RJ-45 console |
Solid State Drive | 1 slot, 120 GB MLC SED |
Memory | 8 GB |
Minimum System Flash | 8 GB |
System Bus | Multibus architecture |
Temperature | 23 to 104°F (-5 to 40°C) |
Relative Humidity | 90 percent noncondensing |
Altitude | Designed and tested for 0 to 10,000 ft (3050m) |
Shock | 50G, 2 m/sec |
Vibration | 0.41 Grms2 (3 to 500 Hz) random input |
Acoustic Noise | 64.2 dBa max |
Temperature | -13 to 158ºF (-25 to 70ºC) |
Relative Humidity | 10 to 90 percent noncondensing |
Altitude | Designed and tested for 0 to 15,000 ft (4570m) |
Shock | 70G, 4.22 m/sec |
Vibration | 1.12 Grms2 (3 to 500 Hz) random input |
AC Range Line Voltage | 100 to 240 VAC |
AC Normal Line Voltage | 100 to 240 VAC |
AC Current | 4.85A |
AC Frequency | 50/60 Hz |
Dual-Power Supplies | None |
DC Domestic Line Voltage | -40.5 to 56 VDC (-48 VDC nominal) |
DC International Line Voltage | -55 to -72 VDC (-60 VDC nominal) |
DC Current | 15A (maximum input) |
Steady State | 75W |
Maximum Peak | 108W |
Maximum Heat Dissipation | 369 BTU/hr |
Form Factor | 1 RU, 19-in. rack-mountable |
Dimensions (H x W x D) | 1.75 x 17.5 x 14.25 In (4.45 x 20.04 x 36.2 cm) |
Weight (with AC Power Supply) | 22.0 lb (10 kg) |
Safety | IEC 60950-1: 2005, 2nd Edition EN 60950-1:2006+A11: 2009 UL 60950-1:2007, 2ndEdition; CSA C22.2 No. 60950-1-07, 2ndEdition |
Electromagnetic Compatibility (EMC) | CE: EN55022 2006+A1: 2007 Class A; EN55024 1998+A1:2001+A2:2003; EN61000-3-2 2009; EN61000-3-3 2008;FCC: CFR 47, Part 15 Subpart B Class A 2010, ANSI C63.4 2009; ICES-003 ISSUE 4 FEBRUARY.2004; VCCI: V-3/2011.04; C-TICK: AS/NZS CISPR 22,2009 KC: KN22 & KN24 |
Industry Certifications | In process |
